CALL RECORDING CARDS & SOLUTION

Call Recording Overview

CALL RECORDING OVERVIEW

Up to 500 Sessions per System, Monitor, Analyze and Record Session over IP/PSTN lines

  • DSP/CPU Encoding
  • Half-Length Size/SDK
  • Full Recording Features
  • Complete Codecs Protocols
Widest Product Range for Passive and Active Call Recording

For two decades Synway has consolidated its position as a leading International call recording cards and software. Because Synway's products and services react rapidly to unpredictable business and industry environments, they provide continual advantages to small, medium and large scaled developers and end users. Synway has widest product range for call recording applications, including passively tapping into analog lines, E1/T1 lines, digital stations, IP networks, wireless radio, radar lines

Unparalleled Commercial Values for Developers and End Users Globally

Based upon its well established products and services for call recording application providers, Synway now is progressing into a new era of growth. To cement its brand as a world-class vendor of call recording hardware, Synway will help clients overcome new challenges in unexpected economic situations and cooperate with more partners, especially public relations partners in the next stage of growth.

Unparalleled Commercial Values for Developers and End Users Globally

Based upon its well established products and services for call recording application providers, Synway now is progressing into a new era of growth. To cement its brand as a world-class vendor of call recording hardware, Synway will help clients overcome new challenges in unexpected economic situations and cooperate with more partners, especially public relations partners in the next stage of growth.

Contact Synway for This Product
Features
Monitor, Analyze and Record Session Over IP lines
Process Up to 500 IP Sessions in A Single System
Support Multiple Recording Formats, Start/Stop Modes
Supports simultaneous monitoring of a variety of protocols on a same line
Support of D-channel events parsing
Support of telephone administration
Support of session administration
Support of RTP administration
Supports configuration of monitoring protocols
Supports a variety of monitoring modes
Supports a variety of recording formats
Supports a variety of RTP streaming formats
Multiple recording methods, including recording of incoming calls, recording of outgoing calls, mix recording of incoming and outgoing calls, are optional
Support volume adjustment
Support DTMF parsing
Capabilities
Flexible Ways to Monitor Protocols and Ports
Multiple Monitoring Modes
Abundant Event Types
Unified D-channel Event IDs
Distributed Architecture
Various Encoding Formats Supported
Supports Standard WAV File
Various RTP Decoding Formats Supported
Supports Memory Recording
Flexible Authorization Strategy
Authorization Code Identification Circuit
Synway’s Unified SynCTI Driver Development Platform
Both file recording and memory recording supported
Supports multiple ways to stop recording
More than one format optional to save the recording file
Core Specifications
Flexible Ways to Monitor Protocols and Ports
SynIPAnalyzer supports the monitoring in a variety of protocols, and will support in more and more protocols. Users can use the relevant configuration items and API functions the driver offers to determine or change the settings on protocol and port monitoring.

Multiple Monitoring Modes
SynIPAnalyzer supports two monitoring modes: Complete and Station. Users can choose or change the mode via API functions to meet different requirements.

Abundant Event Types
SynIPAnalyzer offers a number of event types, including call control event, board state event, media event, terminal event, D-channel event and so on. Users can get enough information from these events to write application programs.

Distributed Architecture
The driver with the distributed architecture has two ends: Master and Slaver. The Slaver can be connected with the Master in two modes: active connection mode and passive connection mode.

Various Encoding Formats Supported
Offers a large selection of encoding formats for storage, including A-Law, μ-Law, ADPCM, PCM16, MP3, GSM. G.729ab

Supports Standard WAV File
The recorded speech files can be edited and played by audio tools such as Cooledit.

Supports Memory Recording
Encoded voice data can be sent back to Master if necessary to let the application program use them more conveniently.

Flexible Authorization Strategy
This software is authorized by USB KEY with a unique serial number. Users may specify the number of authorized channels or upgrade it if not enough. As long as you tell the serial number of your USB KEY to us, we will provide you the upgrade file which you can use to upgrade by yourself.

Authorization Code Identification Circuit
The on-board authorization code identification circuit is designed for software safety. Users can apply to our company for the authorization code.

Synway’s Unified SynCTI Driver Development Platform
Synway owns the intellectual property rights for the unified high-intelligence SynCTI driver development platform. This software can be used with other Synway boards in a same environment, using the unified API functions, configuration items and event interfaces.
